The ALR Universal Beam Clamp provides a versatile and secure suspension point for lifting and pulling operations on structural steel beams. Designed for both vertical lifting and side-load applications, this specialist clamp offers greater flexibility than conventional beam clamps, allowing loads to be applied at various angles across the beam.
Universal Beam Clamps
Key Features
Multi-directional loading capability – Designed for both vertical and side-load applications where conventional beam clamps are not suitable.
Adjustable locking mechanism – Ensures secure and stable clamping to a wide range of beam widths.
Integrated suspension eye – Provides a convenient and low-headroom connection point for hoists and rigging equipment.
Robust steel construction – Engineered for durability in demanding industrial lifting environments.
Typical Applications
Suspending manual or powered hoists from structural beams
Pulling or lifting loads at angles across a beam
Temporary or semi-permanent lifting anchor points
Cross-hauling or fleeting operations
Construction, fabrication, and maintenance lifting tasks
Standards & Performance
Working Load Limits typically available from 2t to 10t depending on model.
Proof load tested to 2 × WLL with a 4:1 safety factor.
Manufactured in accordance with relevant lifting standards such as BS EN 13155 and ASME B30.20.
