The ALR Push Trolley provides a simple and efficient method of traversing lifting equipment along an I-beam or runway beam. Designed for use with manual or powered hoists, the trolley enables smooth horizontal movement and precise positioning of loads during lifting operations.
Push Trolleys
Key Features
Smooth load travel – Precision-machined trolley wheels rotate on sealed bearings for effortless movement along the beam.
Adjustable beam width – Spacer system allows the trolley to be easily configured to suit a wide range of beam flange sizes.
Stable twin-bar design – Twin suspension bars provide increased stability during operation.
Anti-tilt safety feature – Designed to reduce the risk of the trolley disengaging from the beam.
Rubber end stops – Help prevent damage to beam ends and trolley components.
Large suspension eye – Accommodates a wide range of hoist hooks and lifting attachments.
Typical Applications
Suspending manual chain blocks or lever hoists
Moving loads along overhead beams or gantries
Workshop lifting systems
Construction and maintenance lifting operations
Industrial manufacturing and assembly processes
Standards & Performance
Working Load Limit range: typically 500 kg to 10 tonnes depending on model.
Proof tested: 1.5 × WLL.
Safety factor: 4:1.
Manufactured in accordance with BS EN 13157 requirements for manual lifting equipment.
Operating temperature range: approximately -20 °C to +120 °C.
