The ALR Beam Clamp provides a secure and reliable suspension point for lifting and rigging equipment on I-beams and structural steel. Designed for durability and ease of installation, the clamp quickly attaches to beam flanges to create a safe anchorage point for hoists, chain blocks, lever hoists, and other lifting devices.
Beam Clamps
Key Features
Quick and easy installation attachment to I-beams.
Adjustable beam width with locking mechanism enables rapid adjustment to suit different flange sizes.
Heavy-duty construction from high-strength steel for durability and reliability.
Versatile lifting point – Ideal for suspending hoists, trolleys, and other rigging equipment.
Typical Applications
Suspending manual or powered hoists from structural beams
Temporary lifting points in workshops or maintenance environments
Rigging anchor points in fabrication and construction
Gantry and beam-mounted lifting systems
Standards & Performance
Working Load Limits typically available from 2t to 10t depending on model.
Proof load tested to 2 × WLL with a 4:1 safety factor.
Manufactured in accordance with relevant lifting standards such as BS EN 13155 and ASME B30.20.
